- Compact Hybrid band pass cardioid-arrayable subwoofer. Hybrid configuration permit to obtain extension and speed of vented with high SPL and acoustic filtering of band pass
- Suspension hardware fully compatible with MITUS206La allowing the enclosure to be suspended front (FSA model) or rear-firing (FSCA model) for easy cardioid configurations
- Very large area laminar-flow port to ensure no power compression and very low port turbulence
- For cardioid configurations with one SUB rear-firing and two sub front-firing, more than 15db SPL rejection can be obtained behind the array
- 18’’ (460mm) custom B&C neodymium magnet high excursion woofer with 3.5’’ (88mm) voice coil
- Frequency Response from 33Hz to 1Hz
- Class D amplifier delivering 1200WRMS
- Switch mode power supply
- DSP with 8 presets, cardioid and with infra configurations, delay
- Control panel with XLR input and link, volume, presets, delay, phase 0°-180°, ground-lift
- 5/8’’ (15mm) birch plywood enclosure, scratch resistant black paint
- Low frequency extension cabinet for the MITUS 206LA line array for flying or ground stacked configurations.
- Very low profile for a 18’’ size woofer?
Technical Specifications
Code:39682/39715
Configuration:1 Hybrid Bandpass way
Built-in amplifier LF/HF:1200 W RMS
Built-in amplifier peak LF/HF:2400 W
Frequency response:33Hz - 100Hz -6dB
Low Frequency woofer:1x18 - 3.5 coil neodymium inch
Maximum SPL cont/peak:135/139 half space dB
Dispersion:omnidirectional HxV
Input impedance:22 Kohm
Crossover Frequency:preset dependant KHz
AC Power requirements:640 VA
Input connector:XLR with loop
Power cord:5/16.4 m/ft
Net Dimension (WxHxD):576x538x756 / 22.7x21.2x29.7 mm/inch
Net Weight:45 / 99.2 kg/lb
Transport Dimension (WxHxD):700x690x800 / 27.5x27.1x31.4 mm/inch
Transport Weight:55 / 121.2 Kg/lb
